• Blind Spot Assist
• Electronic Pwr Asst Steer
• Ford Co-Pilot360
• Fordpass Connect 4Gwi-Fi Hotspot Telematics Modem
• Lane Keeping System
• Post-Collision Braking
• Pre-Collision Assist W/Aeb
• Rear View Camera W/ Trailer Hitch Assist
• Sync4 W/Evr & 12" Screen
• Usb Ports - 5 Amp

• Air Conditioning
• Assist Handle - B-Pillar
• Assist Handles - A-Pillar
• Center Console W/Storage
• Cruise Control
• Illuminated Sun Visors
• Locking Glove Box
• Powerpoint - 12V (Front)
• Steering - Tilt/Telescopic Wheel With Audio

• 3 Point Safety Belts
• Advancetrac With Rsc
• Airbags – Front, Side And Safety Canopy System
• Brakes - 4Wheel Disc W/Abs
• Securilock Anti-Theft Sys
• Sos Post-Crash Alert Sys
• Tire Pressure Monit Sys

Tow/Haul Mode with Trailer Wiring Provisions

Exterior Upgrade Package – SRW

Passenger Van XLT (302A)

• ORDER CODE 302A
• ENGINE: 3.5L ECOBOOST V6 -inc: 3.73 Axle Ratio GVWR: 9 400 lb
• TRANSMISSION: 10-SPD AUTOMATIC W/OD & SELECTSHIFT -inc: auxiliary transmission oil cooler (STD)
• TOW/HAUL MODE W/TRAILER WIRING PROVISIONS -inc: trailer wiring harness to rear of vehicle for upfit Trailer Sway Control (TSC) 4/7 pin connector assembly and rear jumper This package does not include a Trailer Brake Controller (67D) If a TBC is required it must be added to initial order Neither a Ford nor aftermarket TBC can be added later This package does not include the frame mounted hitch receiver
• Locking/Limited Slip Differential
• Rear Wheel Drive
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Brake Assist
• Wheel Covers
• Steel Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Wheel Covers
• Conventional Spare Tire
• Tow Hooks
• Heated Mirrors
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Power Folding Mirrors
• Rear Defrost
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Rain Sensing Wipers
• Third Passenger Door
• Power Door Locks
• Automatic Headlights
• Automatic Highbeams
• Fog Lamps
• AM/FM Stereo
• Navigation System
• MP3 Capability
• Auxiliary Audio Input
• Smart Device Integration
• MP3 Capability
• Steering Wheel Audio Controls
• Bluetooth® Connection
• Bucket Seats
• Driver Adjustable Lumbar
• Driver Adjustable Lumbar
• Driver Adjustable Lumbar
• Rear Bench Seat
• Adjustable Steering Wheel
• Trip Computer
• WiFi Hotspot
• 3rd Row Seat
• Keyless Entry
• Power Door Locks
• Cruise Control
• Climate Control
• A/C
• A/C
• Rear A/C
• Cloth Seats
• Bucket Seats
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Floor Mats
• Navigation System
• Smart Device Integration
• Rear Parking Aid
• Back-Up Camera
• Rear Parking Aid
• Back-Up Camera
• Rear Parking Aid
• Back-Up Camera
• Front Collision Mitigation
• Power Windows
• Power Door Locks
• Trip Computer
• Immobilizer
• Traction Control
• Stability Control
• Traction Control
• Front Side Air Bag
• Lane Departure Warning
• Driver Monitoring
• Telematics
• Requires Subscription
• Blind Spot Monitor
• Cross-Traffic Alert
• Lane Departure Warning
• Lane Keeping Assist
• Tire Pressure Monitor
• Driver Air Bag
• Passenger Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Passenger Air Bag Sensor
• Back-Up Camera

• Brakes
• Brake ABS System (Second Line): 4-Wheel
• Brake ABS System: 4-Wheel
• Brake Type: 4-Wheel Disc
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.1
• Rear Brake Rotor Diam x Thickness (in): 12.1
• Cargo Area Dimensions
• Cargo Area Length : Floor to Seat 1 (in)
• Cargo Area Length : Floor to Seat 2 (in)
• Cargo Area Length : Floor to Seat 3 (in)
• Cargo Area Width : Beltline (in)
• Cargo Box (Area) Height (in): 77
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume to Seat 1 (ft³): 382.6
• Cargo Volume to Seat 3 (ft³): 107
• Cargo Volume to Seat 4 (ft³): 107
• Doors
• Side Door Type: Sliding
• Electrical
• Maximum Alternator Capacity (amps): 250
• Emissions
• Tons/yr of CO2 Emissions : 15K mi/year
• Exterior Dimensions
• Ground Clearance, Front (in): 6
• Ground Clearance, Rear (in): 6
• Ground to Top of Load Floor (in): 28.8
• Height, Overall (in): 108.6
• Length, Overall (in): 235.5
• Overhang, Front (in): 40.3
• Wheelbase (in): 148
• Width, Max w/o mirrors (in): 81.3
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 25.1
• Interior Dimensions
• Front Head Room (in): 56.6
• Front Hip Room (in): 60.7
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 67.9
• Passenger Capacity: 12
• Second Head Room (in): 65.2
• Second Hip Room (in): 69.6
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 71.4
• Third Head Room (in): 65.2
• Third Hip Room (in): 67.3
• Third Leg Room (in): 35.6
• Third Shoulder Room (in): 67
• Steering
• Steering Type: Rack-Pinion
• Turning Diameter - Curb to Curb (ft): 47.8
• Summary
• Body Code: V
• Body Style: High Roof Van
• Vehicle Name: Ford Transit Passenger Wagon
• Suspension
• Axle Ratio (:1) - Front: 4.10
• Axle Ratio (:1) - Rear: 4.10
• Axle Type - Front: Independent
• Axle Type - Rear: Rigid Axle
• Suspension Type - Front: Strut
• Suspension Type - Rear: Leaf
• Tires
• Front Tire Size: LT235/65SR16
• Rear Tire Size: LT235/65SR16
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Spare Tire Size: Full-Size
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 420
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4200
• Maximum Trailering Capacity (lbs): 4200
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 420
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4200
• Vehicle
• Rear Door Type: Split Swing-Out
• Weight Information
• Base Curb Weight (lbs): 6381
• Curb Weight - Front (lbs): 3257
• Curb Weight - Rear (lbs): 3041
• Gross Axle Wt Rating - Front (lbs): 4130
• Gross Axle Wt Rating - Rear (lbs): 5780
• Gross Combined Wt Rating (lbs): 11200
• Gross Vehicle Weight Rating Cap (lbs): 9500
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 16 X 6.5
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 16 X 6.5
• Spare Wheel Material: Steel
• Spare Wheel Size (in): Full-Size
